MODEL
|
DRT-480-24
|
DRT-480-48
|
|
OUTPUT
|
DC VOLTAGE
|
24V
|
48V
|
|
CURRENT RANGE
|
0 ~ 20A
|
0 ~ 10A
|
|
RATED CURRENT
|
20A
|
10A
|
|
RATED POWER
|
4800W
|
480W
|
|
RIPPLE & NOISE
|
120mVp-p
|
120mVp-p
|
|
VOLTAGE ADJ. RANGE
|
24 ~ 28V
|
48 ~ 53V
|
|
VOLTAGE TOLERANCE
|
1.0%
|
|
LINE REGULATION
|
0.5%
|
|
LOAD REGULATION
|
1.0%
|
|
SETUP RISE TIME
|
1200ms, 40ms/230VAC at full load
|
|
HOLED UP TIME (TYP)
|
16ms/230VAC at full load
|
|
INPUT
|
VOLTAGE RANGE
|
180 ~ 264VAC 250 ~ 370VDC
|
|
FREQUENCY RANGE
|
47 ~ 63Hz
|
|
POWER FACTOR
|
0.7
|
|
EFFICIENCY (Typ.)
|
89%
|
89%
|
|
AC CURRENT (Typ.)
|
4A/230VAC
|
|
INRUSH CURRENT (Typ.)
|
COLD START 40A/230VAC
|
|
LEAKAGE CURRENT
|
<3.5mA / 240VAC
|
|
PROTECTION
|
OVER LOAD
|
105 ~ 150% rated output power
|
|
Protection type : Constant current limiting, recovers automatically after fault condition is removed
|
|
OVER VOLTAGE
|
30 ~ 36V
|
54 ~ 60V
|
|
Protection type : Shut down o/p voltage, re-power on to recover
|
|
OVER TEMPERATURE
|
100 5 (TSW : detect on heatsink of power switch)
|
|
Protection type : Shut down o/p voltage, recovers automatically after temperature goes down
|
|
ENVIRONMENT
|
WORKING TEMP.
|
-20 ~ +70 (Refer to output load derating curve)
|
|
WORKING HUMIDITY
|
20 ~ 90% RH non-condensing
|
|
STORAGE TEMP., HUMIDITY
|
-20 ~ +85 , 10 ~ 95% RH
|
|
TEMP. COEFFICIENT
|
0.03%/ (0 ~ 50 )
|
|
VIBRATION
|
Component:10 ~ 500Hz, 2G 10min./1cycle, 60min. each along X, Y, Z axes; Mounting: Compliance to IEC60068-2-6
|
|
SAFETY &EMC
|
SAFETY STANDARDS
|
UL508, UL60950-1, TUV EN60950-1 approved
|
|
WITHSTAND VOLTAGE
|
I/P-O/P:3KVAC I/P-FG:1.5KVAC O/P-FG:0.5KVAC
|
|
ISOLATION RESISTANCE
|
I/P-O/P, I/P-FG, O/P-FG:100M Ohms / 500VDC / 25 / 70% RH
|
|
EMI CONDUCTION & RADIATION
|
Compliance to EN55011,EN55022 (CISPR22) Class B
|
|
HARMONIC CURRENT
|
Compliance to EN61000-3-2,-3
|
|
EMS
IMMUNITY
|
Compliance to EN61000-4-2,3,4,5,6,8,11, ENV50204, EN61000-6-2 (EN50082-2), heavy industry level, criteria A
|
|
OTHERS
|
MTBF
|
180.9Khrs min. MIL-HDBK-217F (25 )
|
|
DIMENSION
|
227*125.2*100mm (W*H*D)
|
|
PACKING
|
2.4Kg; 6pcs/15Kg/1.75CUFT
|
|
NOTE
|
1. All parameters NOT specially mentioned are measured at 230VAC input, rated load and 25 of ambient temperature.
2. Ripple & noise are measured at 20MHz of bandwidth by using a 12" twisted pair-wire terminated with a 0.1uf & 47uf parallel capacitor.
3. Tolerance : includes set up tolerance, line regulation and load regulation.
4. The power supply is considered a component which will be installed into a final equipment. The final equipment must be re-confirmed that it still meets
EMC directives.
|
