MPD-200

Product:
MPD-200
Model Number:
Description:

Learn more about products detailed description, pricing and service, Please send mail to us!

sales@showlandpower.com

200W 1~4 output medical power supply MPD-200

Features:
* Universal AC input / Full range
* Low leakage current <18 A
* Protections: Short circuit / Overload / Over voltage / Over temperature Free air convection for 140W and forced
air convection for 200W UL60601-1 medical safety approved
* With power good and fail signal output
* Built-in remote ON-OFF control
* Built-in remote sense function
* Fixed switching frequency at 100KHz
* 3 years warranty

Specifications:

Model

Output

Tol.

R&N

Effi.

Power

MPD-200A

5V, 4.0~24A
12V, 0.8~9.6A

±2%
+8%,-5%

80mV
120mV

82%

196W

MPD-200A

5V, 4.0~24A
24V, 0.4~4.8A

±2%
+6.5%

80mV
120mV

83%

196W

Universal AC input / Full range

PF>0.95@230VAC

PG / PF signal output

Protections: SC / OL / OV / OT

Leakage current ≤ 180µA

Built-in remote sense and remote ON/OFF control

Approvals: UL / CUL / TUV / CB / CE

25 CFM forced air cooling

100% full load burn-in test

3 years warranty

AC input voltage range: 90 ~ 264VAC; 127 ~ 370VDC

AC Inrush Current: Cold start, 35A @ 115VAC, 60A @ 230VAC

DC Adjustment Range: CH1: -5 ~ +10% rated output voltage

Overload protection: 110% ~ 160% hiccup mode, auto-recovery

Over voltage protection: CH1: 115% ~ 140% rated output voltage

Leakage Current: Less than 150µA @ 264VAC

Setup, Rise, Hold Up Time: 1000ms, 20ms, 16ms @ full load and 230VAC

Withstand Voltage: I/P~O/P: 4KVAC, I/P-FG: 1.5KVAC, 1 minute

Working Temperature: -20 ~ 70°C (refer to output derating curve)

Safety standards: UL2601.1, TUV EN60601-1, IEC601-1&nbnbsp;approved, design refer to UL 60950-1, TUV EN 60950-1

EMC Standards: EN55011/EN55022 class B, EN61000-4-2,3,4,5,6,8,11, EN61000-3-2,3, EN60601-1-2, ENV50204
