* AC input range selectable by switch
* Protections:Short circuit / Overload / Over voltage
* Cooling free air convection
* 100% full load burn-in test
* Fixed switching frequency at 25kHz
* 2 years warrranty
Specification:
|
MODEL
|
S-150-5
|
S-150-7.5
|
S-150-9
|
S-150-12
|
S-150-13.5
|
S-150-15
|
S-150-24
|
S-150-27
|
S-150-48
|
|
OUTPUT
|
DC VOLTAGE
|
5V
|
7.5V
|
9V
|
12V
|
13.5V
|
15V
|
24V
|
27V
|
48V
|
|
RATED CURRENT
|
30A
|
20A
|
16.7A
|
12.5A
|
11.2A
|
10A
|
6.5A
|
5.6A
|
3.2A
|
|
CURRENT RANGE
|
0 ~ 30A
|
0 ~ 20A
|
0 ~ 16.7A
|
0 ~ 12.5A
|
0 ~ 11.2A
|
0 ~ 10A
|
0 ~ 6.5A
|
0 ~ 5.6A
|
0 ~ 3.2A
|
|
RATED POWER
|
150W
|
150W
|
150.3W
|
150W
|
151.2W
|
150W
|
156W
|
151.2W
|
153.6W
|
|
RIPPLE & NOISE
|
150mVp-p
|
150mVp-p
|
180mVp-p
|
180mVp-p
|
180mVp-p
|
180mVp-p
|
240mVp-p
|
240mVp-p
|
240mVp-p
|
|
VOLTAGE ADJ. RANGE
|
4.5 ~ 5.5V
|
6 ~ 8.3V
|
8 ~ 10.4V
|
10.6 ~ 13.2V
|
12 ~ 15V
|
13.5 ~ 16.5V
|
21 ~ 28V
|
24 ~ 30V
|
43 ~ 53V
|
|
VOLTAGE TOLERANCE
|
2.0%
|
1.0%
|
1.0%
|
1.0%
|
1.0%
|
1.0%
|
1.0%
|
1.0%
|
1.0%
|
|
LINE REGULATION
|
0.5%
|
0.5%
|
0.3%
|
0.3%
|
0.3%
|
0.3%
|
0.2%
|
0.2%
|
0.2%
|
|
LOAD REGULATION
|
0.5%
|
0.5%
|
0.3%
|
0.3%
|
0.3%
|
0.3%
|
0.2%
|
0.2%
|
0.2%
|
|
SETUP, RISE TIME
|
100ms, 50ms at full load
|
|
HOLD UP TIME
|
28ms at full load
|
|
INPUT
|
VOLTAGE RANGE
|
88 ~ 132VAC/176 ~ 264VAC selected by switch 248 ~ 370VDC
|
|
FREQUENCY RANGE
|
47 ~ 63Hz
|
|
EFFICIENCY (Typ.)
|
78%
|
80%
|
80%
|
82%
|
83%
|
84%
|
85%
|
86%
|
87%
|
|
AC CURRENT
|
3.2A/115VAC 1.6A/230VAC
|
|
INRUSH CURRENT
|
COLD START 35A
|
|
LEAKAGE CURRENT
|
<3.5mA / 240VAC
|
|
OTHERS
|
MTBF
|
286.7K hrs min. MIL-HDBK-217F (25 )
|
|
DIMENSION
|
199*110*50mm (L*W*H)
|
|
PACKING
|
0.8Kg; 16pcs/13.8Kg/0.95CUFT
|
